Model NO.:ESVA-028
1) Life time:Minimum 40,000 cycles.
2) Dimensional checking: 100% according to ISO9001.
3) Leakage testing: 100% (in open and close position) .
4) Outlet flow testing: 100%
5)Life cycle testing: 0.05% per shipment.
6) High-low temperature testing: 0.05% per shipment.
CE,CSA certificate available.
application:BBQ, barbecue stove
Capacity:50,000BTU/15KW
lnlet:5/8"-18UNF
Outlet:5/8"-18UNF
Flat Rotation:12:00
1:working temperature:0—80℃
2:working pressure:65mbar1/2PSI
3:smooth moving w/o stop, torque
4:Leakage testing:Air pressure21 kpa for open and
close position,Gas leakage<0.003 L/h
5:Life cycle:40,000times
6:No crash on surface, assembling should be done after
cleaning andwith grease
7:No block with shaftmoving
